171. TIRE MEASURE COUN-TER.—A wheel running freely in theforks of a handle, is made of a size thatwill roll exactly two feet to a revolution,and graduated in feet and inches. Thesupplementary index is set to allow forlap in welding the tire. MEASUREMENT OF POWER. 55 … 171a. THE ST. JOHNS STEAMMETER.—An automatic recordingmeter of the amount of steam passingthrough it for all purposes. The lift-ing of a conical valve by differentialpressure operates a marking indexthrough the lever on a small transfershaft through the projecting arm fromthe cylinder. See detailed…
