Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 70

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 70
i8i. GALLOWAYBOILER.—An in-ternally fired ovalflue,with small con-ical tubes set diago-nallyacrossthe flue. … 182. INTERNAL FIREDCYLINDRICAL TUBULARBOILER.—Lower shell slight-ly inclined to facilitate circula-tion. Fire surface of tubes,fire-box, and all of shell ex-posed to heat, divided by 12,equals boiler horse-power. 183. DION VEHICLE BOILER.—A central water and steam drum enclosed withinan annular…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
