vq flue,with small con-jy ical tubes set diago-nally across the flue. 182. INTERNAL FIREDCYLINDRICAL TUBULARBOILER.—Lower shell slight-ly inclined to facilitate circula-tion. Fire surface of tubes,I fire-box, and all of shell ex-posed to heat, divided by 12,equals boiler horse-power. 183. DION…
