An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 74
203. SHAKING AND TIP-PING FURNACE GRATE, Tupper model. Each sectionrocks on trunnions by a handlever and connecting bar. … 204. SHAKING GRATE for a boiler furnace.— Theflanges are strung uponsquare bars to form eachgrate section, which areshaken or dumped by akey wrench at the front. 64 STEAM POWER.
