t be especially designed to produce a continuous flow of waterthrough it from top to bottom. Figs. 54 and 55 show the outsideftnd the interior construction of a common pattern of indirect radiator 82 HEATING AND VENTILATION 73 designed especially for steam. The arrows in Fig. 55 indicate thepath of… … Fig. 53. Anothsr Form of Indirect Steam or Hot-Water Heater. A very efficient form of radiator, and one that is especially adaptedto the warming of large volumes of air, as in schoolhouse work, is.shown in Fig. 56, and is known as the School fin radiator. This can
