210. AMERICAN BOILER STOKER.—The coal is carried underthe grate from the hopperby a spiral screw and forcedup over the grate. Sid« View of Stokw, … 2 11. MECHANICALSTOKER for a boiler fur-nace, Playford model.The coal is carried into thefurnace from a hopper bya travelling grate. A gatewith rack and gear, oper-ated by a lever, regulatesthe depth of the coal-feed.
