284. PARALLEL MOTION for a ver-tical engine. A, A, radius bars pivoted toengine frame opposite to the middle ofstroke. 285. PARALLEL MOTION for an engine.The radius bars are of equal lengths from thecentre line of the engine and sliding pivot of thelong bar. Both fixed and sliding pivots at… … 286. PARALLEL MOTION of a pistonrod by direct connection with a spur gear ro-tating upon the wrist pin of the crank. Thecrank-pin gear meshes in a fixed internaltoothed gear of double its diameter. One ofthe curiosities of old-time engineering.
