SS6. SMITH ROTARY ENGINE.— Four arms with cylindrical sectors are rotatedaround an axis central to a perforated cylindricalshell. The driven shaft and head discs are ec-centric to the shell. The pressure of steam be-tween the wings tends to push them apart, bywhich the differential leverage on the… … 337. BERRENBERG ROTARYENGINE.—Two intersecting cylindricalshells. The steam cylinder D has twocylindrical pistons, D, D, on oppositesides, that mesh in corresponding cavi-^^§= ties in the cylindrical steam valve, bothrotating in unison by equal external gearing. The steam port passesthrough the…
