Mechanical movements, powers, devices and appliances (1901)
Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 103
342. HOLLY ROTARY ENGINE.— The two geared pistons mesh their longteeth into the recesses of the opposite piston,thus making the sum of the radii betweenthe centres less than the sum of the radiifrom each centre to its cylinder wall. Press- ure rotates the gear in the direction of the longest… … 343. STOCKER ROTARY ENGINE.— The sector pistons are each connected throughcentral concentric shafts to slotted cranks inwhich a sliding box and link connect to a crankon a shaft eccentric to the sector shaft. A differ-ential motion of the sectors is produced whilerotating which rotates the driven…
Mechanical movements
