Mechanical movements, powers, devices and appliances (1901)
Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 149
509. YOKE CONNECTION for a continuouspiston rod and outside crank; crank shaft beyondthe steam cylinder. … 510. REVERSING MOVEMENT for a pump valve. The piston-rod trip carries the ball frame beyond the level, when the ^ ball rolls across and completes the valve throw. 511. DOUBLE-ACTING LIFT AND FORCEPUMP.—In this form the work is the same for eachstroke of the piston, and the pressure equal to…
Mechanical movements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
