HODGES COMPOUND BLOWER.— The action is a triple effect. The air isdrawn in at each side of the blower andthrown out at increasing pressure succes-sively by the fans on each side, and returnedsuccessively by the stationary partitions,with a final discharge at the central annu-lar chamber. AIR POWER… … 628. WEDDING ROTARY BLOWER.—A swinging winged cylinder moving in contact^^ with an outer shell. The wing rides in a slotin the shell with a cavity to give it freedom ofmotion. The central cylinder is driven by acrank-pin or eccentric on a shaft central with theshell
