Mechanical movements, powers, devices and appliances (1901)
Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 190
672. PNEUMATIC HAM-MER.—Constructed on simi-lar lines with No. 673, withthe addition of a counter-balance piston, C, which, by-its reaction and cushion, re-lieves the body of the tool and the hand from excessive jar. 673. PNEUMATIC HAMMER.—F is the flexible hose con-nection. When T is pressed,…
