An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 188
takesplace through S and E, andthe piston P is brought back by means of the pressure in theannular space B, acting only on the collar at D. 674. HOTCHKISS ATMOSPHERICHAMMER.—The hammer-head. A, is connected directly with the piston within the vibrating cylin-der, by a piston rod. The cylinder is…
