Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 246
nioncam teeth locks the wheel teeth until the oppositecam catches its wheel tooth. GEARING. 237 926. PIN WHEEL AND SLOTTED PINION, by which a change of speed is obtained by shifting^ Q ° \^the pinion along its shaft. 927. VARIABLE ROTARY MOTION fromcone gears. A toothed cone is matched to…
Mechanical movements
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
