Mechanical movements, powers, devices and appliances (1901)
Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 252
e dotted sectionat G shows the mesh of the spur, K, of the stopwheel. A is the driving wheel. ^^^^tirtAf^ 957. FAST AND SLOW MOTION SPUR GEAR, or a quickreturn when operating a slide motion by a crank. The driving gear B is composed of gear sectors of differen-tial radius to correspond with the…
Mechanical movements
