Mechanical movements, powers, devices and appliances (1901)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 259

An illustration from Mechanical movements, powers, devices and appliances, 1901, leaf 259 — ear A. Thesmall gear S reverses the mo-tion of the gear F, to shaft ofwhich the arm T is fixed. Thearm T moves backward, carry-ing the pinion S around thebevel gear A, which is fixed to the arm T, giving the bevel wheel F aforward motion, or in the same direction as the arm T. 991. FERGUSONS… … r^i z: I E2 ^k^ ^h^ E3: H to Its shaft P B :i Small dif-ferences in the numberof teeth of each pair ofgears gives a differentialreverse motion to thegears K, H, F.

Mechanical movements
