An illustration from Mechanical movements, powers, devices and appliances, 1901, leaf 276 — 1074. SIX RADIAL GROOVED TRAMMEL and triangular shaft arms, driving or beingdriven by a shaft out of line. The frictionrollers give freedom of motion to either gear. … 1075. RECTILINEAR RECIPROCAT-ING MOTION of a bar, from continuous cir-cular motion of a bent shaft.
