Mechanical movements, powers, devices and appliances (1901)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 347

An illustration from Mechanical movements, powers, devices and appliances, 1901, leaf 347 — 1401. SCREW THREADS, Trape-zoidal thread. Angle 90° face, 450 back.Depth equals 0.75 of the pitch. 33S MILL AND FACTORY APPLIANCES. … ■ POWELLS I*—pHTHREAD

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
