le speed. Thesame arrangement as No. 97, with the addition ofa driving pulley of different size, and a drivenpulley attached to the friction gear on the lowershaft. The right-hand belt shifts to the nextpulley and may be straight or cross, making avariety of motions to the lower shaft. TRANSMISSION… … 100. VARIABLEGEARING. SPEED OR CONE i -av^ c d
