147. FRICTION MACHINE, for testingthe friction of wheels at various speeds andloads. The adjustable circular balance holdsthe wheels or vehicle in place. The poundstension on the scale multiplied by the periph-eral velocity in feet per minute gives the foot-pound draft or friction. so MEASUREMENT… … 148. TORSION DYNAMOMETER.—To a driving shaft E is attachedat C a helical spring. To the otherend of the spring is attached a trans-mission pulley A and a small pulleyK^ Q^, moving freely on the shaft E. AtQo another small pulley is fixed to shaft E. The tension of trans-mission displaces the…
