Mechanical movements, powers, devices and appliances (1901)
Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 68
i8i. GALLOWAYBOILER.—An in-ternally fired ovalflue, with small con-ical tubes set diago-nallyacrossthe flue. 182. INTERNAL FIREDCYLINDRICAL TUBULARBOILER.—Lower shell slight-ly inclined to facilitate circula-tion. Fire surface of tubes,fire-box, and all of shell ex-posed to heat, divided by…
