Marine engines; problems, notes and sketches. Additional to the text-book used in the instruction of naval cadets of the second class, United States Naval Academy (1899)
United States Naval Academy. Dept. of Marine Engineering · Annapolis : Dept. of Steam Engineering, U. S. Naval Academy · leaf 27
e drum F and falls inside thespace around the plate A, from which it enters the upper ends ofthe vertical tubes, as shown by the arrow, falls to C and, rising,pours out of the upper end of the shorter vertical tubes and fallsupon the curved plate. The hanging tubes are seen to hold two smaller… … Fig. 5.—Wards Launch Boiler24
Marine engines
