Mechanical movements, powers, devices and appliances (1901)
Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley & company · leaf 78
227. COMPOUND OSCILLATINGENGINE.—Cylinders at right angles. … 228. TWIN-SCREW OSCILLATING ENGINE.—A through piston rodconnects directly to crank-pins on theshaft face plates. Suitable for smallboats. 229. OSCILLATING HOISTING ENGINE.—The piston rodsare attached to an eccentric strap;one fixed, the other pivoted. A leveroperated by the same eccentric…
Mechanical movements
