Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 126

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in constructive and operative machinery and the mechanical arts, being practically a mechanical dictionary, commencing with a rudimentary description of the early known mechanical powers and detailing the various motions, appliances and inventions used in the mechanical arts to the present time, including a chapter on straight line movements, by Gardner D. Hiscox, 1914, leaf 126
421. CENTRIFUGAL EXHAUST HEAD. - —The exhaust steam head enters the drum tangentially, throwing the particles of water against the outer surface to drip to the bottom. STEAM APPLIANCES. 115 … 421a. THE PULSOMETER STEAMPUMP.—Water is forced from each cham-ber alternately by the steam pressure,while the opposite chamber is filled by thevacuum caused by the condensation of thesteam in contact with the wet surface. Theball valve is very lightly balanced and isthrown over by the alternating…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
