Mechanical movements, powers, devices and appliances; (1903)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 110

An illustration from Mechanical movements, powers, devices and appliances;, 1903, leaf 110 — l dust is charged intothe hopper, passes through ascreen B, and regulated in itsflow by the elastic plates C andD and the link at E. The screw Fregulates the brush pad so thatthe brush throws both air andcoal dust. J are the draft holes,K a screen with a mirror to viewthe fire. Brush makes 900… … BRIDGEWALL I02 STEAM POWER.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
