443. GOVERNOR AND VARIABLE CAM for a gas engine. The centrifugal movementof the governor balls slides the sleeve on thegovernor shaft, and also the variable cam■sleeve, a^ on the driving shaft, by the bell-cranklever, e. The disc roller, b, on an arm of a rockshaft, rolls upon one or the other cams… … 444. INLET VALVE for gas engine.A valve disc slightly held in contact withthe seat by the spring. Air holes should bedrilled close together around the valve seat,so that combined air area shall be largerthan the area of the gas inlet.
