Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 309

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 309
passes just below casting O^,The elbow lever O is so attached tothe carriage, that unless the weightedend is held up, the other end will forcethe rope C^ against the casting 0^°where it will be held firmly as the car-riage runs in, thus causing the pulley O^to revolve, which turns M^ thus raising… … Fig. 163. revolutions while the bobbin was increasing in size.strain on the yarn holds the counter faller down. Hanging on a chain, one end of which is fast to a lever O^^ onthe winding faller shaft, the other end being fastened to a lever O^®on the counter faller, is a rod O^^, the other end of…

Textile fabrics · Textile industry
