Mechanical movements, powers, devices and appliances; (1903)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 140

An illustration from Mechanical movements, powers, devices and appliances;, 1903, leaf 140 — 465. OVERSHOT WATER WHEEL.— Power equals about sixt)^- per cent, of the valueof the water-fall flowing over the wheel. … 466. IRON OVERSHOTWHEEL.—The frame and buck-ets are made of iron or steel.The lightest wheel of its kind. Leffel model. 467. Front view. 132 HYDRAULIC POWER AND DEVICES. ^^v-

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
