Mechanical movements, powers, devices and appliances; (1903)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 166

An illustration from Mechanical movements, powers, devices and appliances;, 1903, leaf 166 — 583. STONEWARE FILTER for household use.The lower jar for storage of filtered water. Theupper jar has a hole filled with sponge that filtersthe dirt out; beneath, a bed of charcoal on a porousstone or earthen plate. … 584. WARD FLEXIBLE PIPEJOINT.—The internal surface of the hubis made spherical. The corrugated pipeend is inserted and the space filled withlead and calked.
