Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 171
610. HYDRAULIC LIFT for a craneor elevator. Section showing cylinder plunger and sheaves. 611. Plan, showing position of valvechamber and valve lever in three directionsfor stop, start, and reverse. The side rodlimits the extreme movement of the plungerby automatically operating the valve Jever.…
Mechanical movements
