Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 191
COMPRESSED AIR SHEEP-SHEARING MACHINE.—Asmall piston vibrates and oper-ates the cutters through a leverwith a diagonal slot in which apin in the piston-rod head slides.An arm on the piston rod oper-ates the valves. … 677. PORTABLE RIVETER, Allenmodel. The toggle joint is pivoted to a camand also within the trunk piston. By thedifferential trunk form, the return stroke econ-omizes the compressed air, the large pistonarea giving great power to the riveting stroke.
Mechanical movements
