Mechanical movements, powers, devices and appliances; (1903)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 256

An illustration from Mechanical movements, powers, devices and appliances;, 1903, leaf 256 — 976. CONTINUOUS SHAFT MO-TION from an alternating driving shaft.The ratchets fixed to the bevel gears onthe shaft a are operated by pawls fixedto the shaft, the rocking of which re-volves the bevel gear and shaft B in onedirection. … 977. ALTERNATING MOTION of a shaftat right angles to a driving shaft by three bevelgears and double clutch. Bevel gears on clutchshaft run loose. Clutch slides on a feather orkey, and is operated by a Y-lever and groove inclutch. ECCENTRIC WHEEL TRAIN. — The elliptical bevelgear A isfixed to the…

Mechanical movements
