Mechanical movements, powers, devices and appliances; (1903)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 259

An illustration from Mechanical movements, powers, devices and appliances;, 1903, leaf 259 — 988. PLANETARY MOTION applied to anapple-paring machine. The gear F is fixed to thecrank shaft. The internal spur gear A is stationary.On turning the crank the pinion B rolls forward,carrying the arm T at half the velocity ofthe crank. The bevel gear A revolves withthe crank, driving the spindle K… … 989. PLANETARY GEARTRAIN.—The arm T revolvesaround the fixed gear A, on thestand H. The gear B and bevel^gear E are fixed on a shaft andturn in one direction, giving a contrary motion to the bevel gear F and index hand P. 990. PLANETARY GEARTRAIN. The arm T revolvesaround the fixed gear A. Thesmall…
