Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 300
1184. LEVER ESCAPEMENT.—Theanchor pallet B is attached to the lever C E,at the end E of which is a notch to receivethe pin in the balance-wheel disc D. The im-pulse is given to the balance wheel at themiddle of its oscillation by the escape of theteeth from the stop surface to the impulseplanes of… … ii8q. LEVER CHRONOMETER ESCAPE- 0- MENT, single-pallet impulse. The lever palletsalternately lock the escapement by the throw ofthe lever; the oscillating pin on the pallet discdrops into the fork of the lever, throwing itagainst the stop pins at its other end. 1186. ARNOLD…
Mechanical movements
