Weaving; a practical guide to the mechanical construction, operation, and care of weaving machinery, and all details of the mechanical processes involved in weaving (1909)

American School of Correspondence, Nelson, H. William (Hector William), b. 1869 · Chicago, American School of Correspondence · leaf 28

An illustration from Weaving; a practical guide to the mechanical construction, operation, and care of weaving machinery, and all details of the mechanical processes involved in weaving, 1909, leaf 28
Fig. 13. out. Also, when the faller rod is down and there is some slackyarn to be taken up, the machme should be run slowly until theyarn is tightened and the ends are traveling straight from thespool. The slow motion is obtained as follows : an additionalpulley (see Fig. 13) is placed on the…
