Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 346
1398. SCREW THREADS.—StandardV thread, sharp at top and bottom. Depthequals 0.85 of the pitch. Angle 60°. U.S. S. THREAD … 1399. SCREW THREADS.—UnitedStates Standard Thread. Flat top andbottom. Depth equals 0.65 of the pitch.Angle 60°. 1400. SCREW THREADS, Whit-worth thread. Rounded top and bot-tom. Depth equals 0.75 of the pitch.Angle 550. TRAPEZOIDAL ^-p^-,THREAD I 1
Mechanical movements
