An illustration from Mechanical movements, powers, devices and appliances;, 1903, leaf 376 — 1530. PERSPECTIVE CENTRO- LINEAD.—The edges of legs on the sides a^ b^ and c must be in line with their common ~ axis, with clamp screws to hold the movable legs in their set position. The directing pins b and c should be set on the radial lines of the back point of the perspective, when the long… … 1531.SPHEROMETER.—For meas-uring the curves of spherical surfaces orof templates of lenses by means of agraduated follower at the centre betweentwo bearings. The scale and nonius arecomputed for the versed sine of a fixedchord length.
