99. TWO SPEED GEAR from belt pulleys andone hollow shaft. A solid shaft with loose pulley (a)and fast pulley (J?), fast pulley [c) on hollow shaftcarrying large driving gear at the right. c ^ j - ^ ^^^ = J=; :| fr 1 a ~b c 100. VARIABLEGEARING. SPEED OR CONE a, tight pulley on outside hollow shaft.… … loi. TRANSMISSION OF POWER froma horizontal shaft to two vertical spindles. Asingle belt, with two idlers, for tightening anddirecting the half twist of the belt. 102. FRICTIONAL RECTILINEARMOTION, from the angular position of asheave or pulley rolling on a revolving barrelor long cylinder. A,…
