Appleton's cyclopædia of drawing, designed as a textbook for the mechanic, architect, engineer, and surveyor (1866)

Worthen, William Ezra, 1819-1897, [from old catalog] ed, Appleton, firm, publishers, New York. (1866. D. Appleton & co.) [from old catalog] · New York, D. Appleton and company · leaf 146

An illustration from Appleton's cyclopædia of drawing, designed as a textbook for the mechanic, architect, engineer, and surveyor, 1866, leaf 146
or X of it. Let the inclined plane ahd^ Fig. 198, bebent round, and attached to the drum A,Fig. 200, to which motion of revolution onits axis is given, by the unwinding of the turns of a cord from around itsperiphery, through the action of a weight P suspended from a cord passingover a pulley. If… … ^! 1 A Fio. 200. no MECHAlSnCS.
