Mechanical movements, powers, devices and appliances; (1903)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 46

An illustration from Mechanical movements, powers, devices and appliances;, 1903, leaf 46 — ng on a revolving barrelor long cylinder. A, forward motion; B, stop.The principle of the Judson railway pro-pulsion. Efhciency was increased by the use of a small truck withseveral roller pulleys. 103. VARIABLE ROTARY MOTION froma friction pulley traversing a concave conicaldrum. The speed ratio… … 38 TRANSMISSION OF POWER.

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
