Mechanical movements, powers, devices and appliances; (1903)
Hiscox, Gardner Dexter, 1822?-1908 · New York, The N.W. Henley & co. · leaf 81
241. MEYER CUT-OFF VALVE.—C, D, Slide valve \\-ithperforated ports. The supplementan- or cut-off valves are adjustedto the required distances, to meet the required cut-off, by a right andleft screw, which has an index H, and wheel G, for turning the screwfor cut-off adjustment on the outside of the… … 242. SINGLE D, SLIDE VALVE,with double steam and exhaustports. Central steam ports open - into steam chest at the side of the v?avc.
Mechanical movements
