Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 106

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 106
363. DAKE SQUARE PISTONENGINE. — Two rectangular pistons,one within the other, working at rightangles in the outer piston. The innerpiston is connected to the crank pin,and moves vertically. The outer pistonmoves horizontally in the case. Theprinciple is similar to the Root SquareEngine, No. 362.… … 364. « WILKINSONS STEAMTURBINE. —Two rim-pocketeddiscs running against the disc surfacesof a shell with oblique steam ports.The discs are feathered on the shaft,and held against the faces of theshell by springs. A groove aroundI the shell opposite the pockets allowsthe steam to pass around to the…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
