Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 141

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 141
477. BUCKETED WATER-RAISINGCURRENT WHEEL.—The buckets arepivoted to the outside rim of the wheel, andtilted into the trough at the top by a tail-piece on the bucket striking the trough. … 478. CURRENT WHEEL WATERLIFT.—The water buckets and arms aretroughs that carry the water to the centralhollow shaft, from the end of which it isdischarged into a trough. Used for irrigation and low-grade water supply.
