Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 143

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 143
488. TURBINE AND GATE.—A downwardflow from angular fixed guides in the waterchamber. … 489. LANCASTER TURBINE, downwarddischarge. The upper parts of the blades are vertical,and receive water tangentially from the gate plates.
