Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 149

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 149
519. DIAPHRAGM PUMP, in which a flexi-ble diaphragm is used instead of a piston. … 520. FAIRBURN BAILING SCOOP,for low-lift drainage or irrigation. The tiltingscoop may be connected to a walking beam ordirectly to a vertical engine. JU^ 521. ^

Mechanical movements
