Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 155

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 155
and water will take its place without stopping the runningof the siphon. 148 HYDRAULIC POWER AND DEVICES. 546. SIPHON and its operation. A,An air catch; H, G, terminal cocks to be closed when fill-ing the siphon.Open cock at D,=^^- and pump thesiphon and fun-nel full. Closecocks D and F and open H…
