Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 164

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 164
585. FLEXIBLE BALL JOINT. — Flanges are cast upon the spherical ends of the pipes.The joint is packed with a lead ring and drawntogether with, bolts at any angle within its limit. … 586. FLEXIBLE PIPE JOINTS, forsubmarine pipe lines. The head joint isfirst made up in the gland. The flangejoint is bolted when the pipe is laid in lineready for lowering. 587. FLEXIBLE PIPE JOINT, in whichthe lead joint is made between a dividedsocket, which does not require the pouring ofmelted…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
