Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 166

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 166
596. MULTIPLE RING VALVE, for k enlarged valve area with small lift. i … 597. DOUBLE-BEAT PUMP VALVE, Cor-I nish model. The upper seat is supported by across-bar, in which is fixed the guide-pin thatI carries the valve.
