Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 176

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 176
HODGES COMPOUND BLOWER.— The action is a triple effect. The air isdrawn in at each side of the blower andthrown out at increasing pressure succes-sively by the fans on each side, and returnedsuccessively by the stationary partitions,with a final discharge at the central annu-lar chamber. AIR POWER… … 628. « WEDDING ROTARY BLOWER.—A swinging winged cylinder moving in contactwith an outer shell. The wing rides in a slotin the shell with a cavity to give it freedom ofmotion. The central cylinder is driven by acrank-pin or eccentric on a shaft central with theshell

Mechanical movements
