Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York : The Norman W. Henley publishing co. · leaf 189

An illustration from Mechanical movements, powers and devices; a treatise describing mechanical movements and devices used in construcive and operative mechinery and the mechanical arts, being practically a mechanical dictionary, 1917, leaf 189
COMPRESSED AIR SHEEP-SHEARING MACHINE.—Asmall piston vibrates and oper-ates the cutters through a leverwith a diagonal slot in which apin in the piston-rod head slides.An arm on the piston rod oper-ates the alves. … 677. PORTABLE RIVETER, Allenmodel. The toggle joint is pivoted to a camand also within the trunk piston. By thedifferential trunk form, the return stroke econ-omizes the compressed air, the large pistonarea giving great power to the riveting stroke.

Mechanical movements
